Road Construction Gasoline Tamping Rammer / Honda Vibrating Tamper Rammer

Road Construction Gasoline Tamping Rammer / Honda Vibrating Tamper Rammer

    • small.img.alt
    • small.img.alt
  • large.img.alt

    Product Details:

    Place of Origin: JIANGSU CHINA
    Brand Name: KONSTANT
    Certification: CE
    Model Number: KT-RM82

    Payment & Shipping Terms:

    Minimum Order Quantity: 5pcs
    Price: Negotiated
    Packaging Details: 1 set/ carton
    Delivery Time: 30days
    Payment Terms: L/C, T/T
    Supply Ability: 500pcs/month
    Contact Now
    Detailed Product Description
    High Light:

    Tamper Rammer

    ,

    Tampering Rammer



    Road Construction Gasoline Tamping Rammer / Honda Vibrating Tamper Rammer





    Specification:



    Model KT-RM82
    Engine Honda GX120 Robin EH12-2D
    Type of Combustion Air-cooled,single cylinder,4-stroke
    Power kw(hp) 3.0(4.0) 3.0(4.0)
    Impact force kn 15
    Jumping Sroke mm(in) 50-80(2.0-3.2)
    Plate size mm(in) 340x280(13.4x11)
    Weight kg 83
    Carton size mm 770x480x1150
    Load quantity 144pcs/40GP


    Description:



    Compacting the gravel, clay and sand, can be used in the compactness of the road, bridge foundation, house, reservoir dam, especially the narrow worksite, such as the floor inside the house, yard and trench. it is competent at the construction that the large and middle impacting machinery can not do.



    Gasoline tamping rammer are driven by 4-stroke petrol engines designed specially for rammers. No need to mix fuel and oil, easy starting ,low-noise operation, low maintenance and reduced fuel consumption. Electric rammer are  more friendly for environment.



    A heavy duty throttle control provides more reliable and longer service.



    Additional built-in air filtration system plus the original air cleaners in the engine provides cleaner air to engine for longer life and improvident durability.



    An integrated fuel valve provides for easy starting.



    Heavy shock mount system to reduce hand-arm vibration and improve operator comfort.



    Plastic oil tank offers longer life and rust-free



    Rammer shoe made of steel plate with wooden insert offers economical usage.



    Special protective frame for engine ,prevents any possible damage on tough jobsite.



    Specially designed trolley kit for easy transportations.



    High quality polyurethane sheath accept more compacting force, offers a reliable lubricating system.



    Applications:



    Compacting the gravel, clay and sand, can be used in the compactness of the road, bridge foundation, house, reservoir dam, especially the narrow worksite, such as the floor inside the house, yard and trench. it is competent at the construction that the large and middle impacting machinery can not do.



    Competitive Advantage:



    Honda GX120 is designed for tamping rammer

    No need to mix fuel and oil, easy starting, low-noise operation, low maintenance and reduced fuel consumption comparing to 4-stroke engine.

    High quality, Chinese made bellow.  German bellow is optional.

    Heavy shock mount system to reduce hand-arm vibration and improve comfort

    Rammer shoe made of steel plate with wooden insert offers economical usage

    Special protective frame for engine, prevents any possible damage on tough job site

    Additional built-in air filtration

    Optional wheel kit for easy transportation.
